2200 Corrugated Cardboard Production Line

1. Product introduction

The 2200 Corrugated Board production line is an efficient, fully automated production equipment specifically designed for the production of corrugated board with a width of 2200mm. The line integrates advanced manufacturing technology and automated control systems to meet different specifications and needs of corrugated board production. It is widely used in packaging, protection and other fields, is the core production equipment of carton packaging enterprises.

‌2. Main components ‌

2200 corrugated board production line is mainly composed of two relatively independent process segments: wet end equipment and cadre equipment:

Wet end equipment: mainly includes base paper holder, automatic paper feeder, preheating and preheater, single-side corrugating machine, paper feed bridge, gluing machine, double-side machine and so on. The main function of the wet end equipment is to make three, five, seven layers of corrugated cardboard with different corrugated combinations through pressing, gluing, bonding and other processes.

Cadre equipment: mainly including rotary cutting machine, slitter indentation machine, cross cutting machine, stacker and so on. The cadre equipment will be the wet part of the production of corrugated board in accordance with the order requirements for longitudinal cutting, indentation, cross cutting and stacking, and finally output finished corrugated board.

‌3. Technical features ‌

High efficiency automation: the whole production line is controlled by computer to achieve automatic production, improve production efficiency and reduce manual intervention.

Multi-corrugated type quick replacement: The single-side corrugated machine in the wet end equipment adopts the rapid roll change technology, which can replace the corrugated type without moving out, reducing the roll change time and improving production efficiency.

High-precision control: The production line is equipped with advanced control system, which can realize the precise glue amount control, cardboard size control, etc., to ensure product quality.

Environmental protection and energy saving: The production line adopts energy-saving design to reduce energy consumption, and is equipped with equipment such as dust removal and noise reduction to reduce the impact on the environment.

‌4. Scope of application ‌

2200 corrugated cardboard production line is suitable for packaging needs of various industries and products, including catering, clothing, chemical, food, toys, etc. It can produce various specifications of corrugated cardboard for the production of packaging boxes, large cartons, fast food lunch boxes, light or heavy transport packaging.

5. FAQ

What is the maximum production width of 2200 corrugated board production line? ‌

A: The maximum production width of 2200 corrugated board production line is 2200mm, which can meet most of the production needs of corrugated board.

What are the functions of wet end equipment and cadre equipment in the production line? ‌

A: The wet end equipment is mainly responsible for the corrugated base paper through pressing, gluing, bonding and other processes to make different combinations of corrugated cardboard; The cadre equipment is responsible for cutting, indentation, cross cutting and stacking the corrugated cardboard produced by the wet part according to the order requirements, and finally output the finished corrugated cardboard.

How to ensure the quality of corrugated board production? ‌

A: The key to ensuring the quality of corrugated board production lies in the precise control of equipment and the quality of raw materials. The production line adopts advanced control system, which can realize accurate control of glue amount and cardboard size. At the same time, the selection of high-quality raw materials is also an important factor to ensure product quality. In addition, regular maintenance and maintenance of the equipment to ensure that the equipment is in the best working condition is also an important measure to ensure the quality of production.

Does the production line support quick change of corrugated type? ‌

Answer: Yes, 2200 corrugated board production line supports fast replacement of corrugated type. The single side corrugator in the wet end equipment adopts rapid roll change technology, which can replace the corrugated shape without moving out, greatly reducing the roll change time and improving the production efficiency.

Does the production line produce noise and dust during operation? How to deal with it? ‌

A: The production line does produce some noise and dust during operation. In order to reduce the impact of noise and dust on the environment and workers, the production line is equipped with equipment such as dust removal and noise reduction. Dust removal equipment can effectively collect and treat the dust generated in the production process; Noise reduction devices reduce noise levels through sound insulation, sound absorption and other measures. In addition, regular maintenance and maintenance of the equipment to ensure that the equipment is in good working condition also helps to reduce noise and dust generation.

What auxiliary equipment should be equipped with the production line? ‌

A: In order to ensure the normal operation of the production line, it is usually necessary to be equipped with some auxiliary equipment, including steam boilers, compressed air systems, glue supply systems, etc. Steam boilers are used to provide steam for the production line; The compressed air system is used to power the pneumatic components in the production line; The glue supply system is responsible for providing a stable glue supply to the glue applicator. The configuration of these auxiliary devices should be selected and configured according to the specific needs of the production line.

Does the line support customized production? ‌

A: Yes, 2200 corrugated board production line supports customized production. According to the specific needs and order requirements of customers, the production line can be customized design and transformation to meet the production needs of different specifications and models of corrugated cardboard. Customized production can greatly improve the flexibility and adaptability of the production line to meet the diversified needs of customers.
