Rotary Slotter Machine

1. Rotary slotting machine product introduction

Rotary Slotter Machine (Rotary Slotter Machine) is a high-efficiency mechanical equipment, mainly used for grooving, cutting and forming on a variety of materials and other processing operations. The equipment is widely used in wood processing, metal manufacturing, plastic processing and other industries, which can significantly improve production efficiency and meet the requirements of modern industry for precision and efficiency.

2. How it works

The rotary slotting machine uses an electric motor to drive the rotary tool, which can cut the desired notch in the material when the tool is rotated at high speed on the surface of the material. Its working principle mainly includes the following steps:

Material fixation: The material to be processed is fixed on the workbench to ensure that the material does not move during processing.

Tool selection: According to the characteristics of the material and the requirements of the notch, choose the appropriate tool.

Parameter setting: Set cutting depth, feed speed and other parameters to optimize the machining effect.

Slotting: Start the rotary slotting machine, the tool rotates and cuts at a predetermined position to complete the notch processing.

Completion inspection: After the machining is completed, check the size and surface quality of the notch to ensure compliance with the standard.

3. Product features

High efficiency: The rotary slotting machine uses high-speed rotating tools, which can complete a large number of processing tasks in a short time, significantly improving production efficiency.

High precision: The equipment is equipped with a high-precision control system, which can be accurately cut according to the set parameters to ensure the consistency of the notch size.

Multi-function: The rotary slotting machine can be adapted to the processing needs of a variety of materials, including wood, synthetic materials, metals and plastics, and has a wide range of applicability.

Easy to operate: Modern rotary slotting machines are generally equipped with numerical control systems, simple operation, users only need to enter processing parameters to complete complex slotting tasks.

Safety: The equipment is designed with multiple safety protection devices, such as emergency stop switch, protective cover, etc., to ensure the safety of the operator.

4. Technical parameters

Electric motor power: 5-15 kW

Tool speed: 3000-6000 RPM

Cutting depth: 0-50 mm (adjustable)

Cutting width: 3-20 mm (adjustable)

Table size: 1000 x 600 mm

Weight: About 800 kg

Control mode: manual/numerical control

5. Application field

Rotary slotting machines are widely used in many industries, including:

Wood processing: used to make notches for furniture, floors, doors and Windows, etc., to ensure tight connection between components.

Metal processing: In the manufacture of metal parts, precise slotting is carried out to ensure the assembly accuracy of parts.

Plastic processing: Slot and cut plastic materials, widely used in electronic products shell, household appliances and other fields.

Electrical industry: In the manufacture of electrical equipment, it is used for the processing of wiring slots to improve the safety and aesthetics of equipment.

6. FAQ

What is a Rotary Slotter Machine?

A Rotary Slotter Machine is a mechanical device used for slotting operations on cardboard or similar materials. It uses a rotating tool or mold to accurately cut the groove line when the material passes through at high speed, preparing for the subsequent carton and carton molding. This machine is often used in the packaging industry and is one of the key equipment on the carton production line.

How does the Rotary Slotter Machine work?

It is mainly based on the principle of rotary cutting. The cardboard is fed into the machine by the conveyor system, and the rotary slotting tool inside the machine is rotated at high speed under the drive of the motor. When the cardboard passes through the rotating tool, the tool cuts the slot in the cardboard according to the preset depth, width and position, and the cutting action is continuous and fast, resulting in an efficient slotting process. At the same time, the equipment is usually equipped with accurate positioning and control systems to ensure the accuracy of the slot.

What is the cardboard thickness range it can handle?

Different models of Rotary Slotter machines can handle different cardboard thickness ranges. In general, common machines can handle 1-10mm cardboard, but some specially designed machines may be able to handle thicker or thinner materials. The specific thickness range depends on the design parameters of the machine, including the strength of the tool, the power of the transmission system, and the overall structure of the equipment.

How fast is the Rotary Slotter Machine slotted?

Slotting speed varies according to machine specifications and performance. Small or medium-low speed Rotary Slotter machines may be slotted 30-100 times per minute, while large, high-speed equipment can achieve 200-500 times per minute or even higher slotting times. The speed mainly depends on the rotating tool speed of the machine, the cardboard conveying speed and the degree of automation of the equipment.

Can the size and shape of the slot be adjusted?

Yes, the size and shape of the slot can be adjusted. It is usually possible to change the width and depth of the slot by changing the rotary slotting tool of different specifications. For more complex grooving needs, special dies or tool combinations can be used. Some advanced machines are also equipped with electronic control systems that can precisely adjust the position and Angle of the slot within a certain range to meet a variety of product design requirements.

Does this machine have any requirement on the hardness of the cardboard?

Rotary Slotter Machine has a certain range of adaptability to the hardness of cardboard. In general, it can handle ordinary hardness of cardboard, such as carton cardboard used to pack common goods. However, if the cardboard is hard, it may accelerate tool wear, and may even lead to tool damage or reduced slotting accuracy. If the cardboard is too soft, there may be problems such as uneven slotted edges. When dealing with cardboard of special hardness, it may be necessary to adjust the tool and pressure parameters of the machine properly.

How to ensure slotting accuracy during machine operation?

In order to ensure the accuracy of slotting, the Rotary Slotter Machine adopts a variety of technologies. First, it is equipped with a high-precision positioning system, such as photoelectric sensors or encoders, for precise control of the cardboard delivery position. Secondly, the installation of the rotating tool and the concentricity of the rotating axis are strictly calibrated to ensure the accuracy of the cutting position of the tool during the rotation process. In addition, the control system will monitor and adjust the operating parameters of the machine in real time, such as adjusting the cutting depth according to the tension change of the cardboard, so as to maintain the accuracy of the grooving.
